Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine

Name: Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine
Brand: SANROCK
Price: 1 USD

Quality Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine for sale

Brand Name : SANROCK

Model Number : SRUJ120-2

Certification : CE ISO 9001:2015

Place of Origin : Zhejiang, China

MOQ : 1Set/Sets per Month

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 300Set/Sets per Month

Delivery Time : 40-60days

Packaging Details : Nude package for machines, Wooden box package for spare parts, Or customer demand.

Product name : Underground Jumbo Drilling Rig

Name : Jumbo drilling rig

Type : Rotary Drilling Rig

Power(w) : 122KW/142KW

Drilling Diameter : 45-102mm, 45-64mm

Drilling Depth : 52m

Power Type : Diesel

Working Pressure : 25bar

Traveling speed : 14Km/h

Rotational torque(Max) : 1000N.m

Boom extension : 1800mm

Hydraulic oil tank ,volume : 350L

Propel compensation : 1800mm

Impact pressure, : 220Bar

Max.system pressure : 230bar

Use : Ore Mining

Application : Engineering Construction,Tunnel

Machine type : Drilling Equipment

Feature : High Drilling Efficiency,Competitive Price

Warranty : 1 Year

Dimension(l*w*h) : 16129*2475*2918/3618mm

Contact Now

Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine

SRUJ120/2 two booms drilling jumbo is specially designed for tunnels of high-speed railway, water conservancy and hydropower projects, national defense and other medium and large-scale tunnel excavation and drilling operations. It can meet the needs of drilling various blast holes, anchor bolt holes, small pipe support, groutingholes, etc.
Two sets of independent hydraulic systems of drill booms are used to control each other without interference. A set of aerial work platform is designed for auxiliary work such as blasting charge, danger elimination, mesh hanging, etc.

Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine

Products Description

Rock Drill
Model No.	1838ME	2238
Shank	T38/T45	T38/T45
Hole diameter, mm	45-64	45- 102
Max.impact power,Kw	18	22
Impact frequency,Hz	60	73
Impact pressure,Bar	220	220
Rotation system	Independent rotation	Independent rotation
Rotation speed, rpm	0-215	0-215
Max.rotation torque Nm	1000	1000
Lubrication air displacement L/s	7	7
Weight,Kg	170	174

Feed
Length,mm	5315	5915	6756	7393
Drill rod Length,mm	3700	4300	4915	5525
Hole depth,mm	3400	4000	4600	5200
Weight ,kg	560	594	700	800
Propulsion force ,Kn	15	15	15	15

Overall Dimension
LWH,mm	1612924752918/3618
Ground Clearance mm	350
Weight kg	35000
Traveling Speed, Km/h	14

Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine

Company Profile

Jumbo Drilling Rig Tunnel Rock Borehole Drilling Equipment Underground Drilling Machine

1.What can you buy from us?

DTH drilling rig,Integrated DTH DTH drilling rig ,core drilling rig,highway pile driver,solar pile driver ,anchor pile driver,rotary drill rig ,Top Hammer drill rig,Underground jumbo drill rig ,DTH hammer,screw air compressor,screw air compressor,piston air compressor,pneumatic rock drill ,drill rod,drill bit,PDC drill bit,top hammer drill bit,tricone bit ,spare parts.

2.How can I make payment?

A:You can pay by credit card, TT, Western Union, LC etc.

3.How is the shipment? How long dose it take?

A: For large quantity or heavy products, we ship by sea shipping or land shipping. Shipping efficiency depends on country and city you want to ship to. For small and delicate products, we ship by DHL, UPS, Fedex or TNT. You can also appoint shipping method you like before we ship.

4.How is your quality control?
A: We have our own experienced QC. There will be strict inspection and testing for every order before shipping out.
